Detail SNC-DH280
Brand Sony
Model Code SNC-DH280
Colour Type Colour / Monochrome
Chip Inch Size 1/ 3
Resolution TVL 600
Network/ IP Type Yes
Dome Type Variable Focus
Sensitivity lux 0.0
Indoor/ Outdoor Outdoor
Optical Range mm 3.1 ~ 8.9
Compression H.264, MPEG-4, JPEG
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1 ~ 10, 000
S/ N ( Signal/ Noise) Ratio dB 50
Video Output PAL/ NTSC
Network Properties Interface: 10 BASE-T / 100 BASE-TX ( RJ-45)
Network Protocols: IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP*
Image Frame Rate: 30fps
Electrical Specifications Voltage: 12 V DC, 24 V AC, PoE
Power Consumption: 29 W
Physical Specifications Dimensions mm: 166 x 119
Weight g: 1, 400
Environmental Specifications Operating Temp oC: -30 ~ + 50
Protection: IP66
System Requirments Operating System: Windows Xp, Windows Vista
Web Browser: Microsoft Internet Explorer Ver 6.0, Ver 7.0
Model Info
* HTTPS, FTP ( client/ server) , SMTP, DHCP, DNS, NTP, RTP/ RTCP, RTSP, SNMP ( MIB-2) .
